30P LVDS Cable Assembly – UL1354 36# & 40# 50Ω – Medical Grade Compatible

Why Choose LVDS Cable?

High-Speed Differential Cable for Reliable Display and Data Transmission

LVDS Cable is widely used in LCD Displays, LED Displays, Notebooks, Monitors, Industrial Displays, Medical Equipment, Automotive Electronics, and other electronic devices that require high-speed differential signal transmission.

We can provide complete solutions ranging from standard LVDS Cable to custom LVDS Cable Assembly, and can be customized according to the customer’s transmission rate, channel quantity, cable structure, length, impedance, shielding method, and connector requirements.

Product Structure

The typical LVDS cable can adopt twisted-pair, parallel-line or micro-coaxial structure depending on different applications.

Typical Structure

Conductor → Insulation → Twisted Pair / Differential Pair → Shield → Outer Jacket

For high-density and high-speed applications, the following methods can also be adopted:

Micro Coaxial Structure → Shielding → Cable Assembly

Conductor

The conductor is responsible for the transmission of high-speed differential signals, and the choice can be made according to the application requirements:

Bare Copper

Tinned Copper

Silver-Plated Copper

Copper Alloy

The appropriate conductor material can be selected based on electrical performance, flexibility, wire diameter and application environment.

Common structures include:

Twisted Pair

Parallel Pair

Shielded Pair

Micro Coaxial Pair

I Key Advantages

1. High-Speed Differential Signal Transmission

LVDS employs differential signal transmission technology, which can meet the requirements of high-speed data transmission and is suitable for applications such as display, image processing, and high-speed data interfaces.

2. Excellent Noise Immunity

Differential transmission can effectively suppress common-mode noise and maintain stable signal transmission performance in complex electromagnetic environments.

3. Low EMI

LVDS uses low-voltage differential signals, which can reduce signal swing and electromagnetic radiation, thereby helping to meet the EMC/EMI requirements of electronic devices.

4. Low Power Consumption

The lower signal voltage swing enables LVDS to have excellent power consumption performance during high-speed transmission, making it suitable for electronic devices with high requirements for power consumption and heat dissipation.

5. Controlled Differential Impedance

By precisely controlling the spacing of conductors, the thickness of insulation layers, the structure of wire pairs, and the shielding method, stable differential impedance can be achieved, reducing reflections and distortions in the transmission of high-speed signals.

6. Low Crosstalk

A reasonable Pair Structure, Twisting Ratio and Shielding Design can reduce crosstalk between different signal channels and enhance the reliability of multi-channel high-speed transmission.

7. Flexible Cable Design

The LVDS cable can adopt different wire diameters, core numbers, arrangement methods and shielding structures according to the internal space of the equipment, making it suitable for narrow spaces and complex wiring environments.

Customized Cable Assembly

we can from Cable Design → Material Selection → Differential Pair Design → Connector Matching → Cable Assembly → Electrical Testing，Provide a complete LVDS Cable solution.
